    HD CCTV Pipe Inspection Equipment 360 Degree Drain Camera System

    Ask Lasest Price
    Brand Name : Trio-Vision
    Model Number : TVS-15
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 20units per month
    Delivery Time : 4-8 weeks
    • Product Details
    • Company Profile

    HD CCTV Pipe Inspection Equipment 360 Degree Drain Camera System

    HD CCTV Pipe Inspection Equipment 360 Degree Drain Camera System

    Cctv Pipe Inspection Cameras Brief introduction:


    CCTV Pipe Inspection Robot is mainly used in electricity, municipal, traffic, petrifaction, construction and it is suitable for inspecting the boiler, pipeline, underground cable channel and places will do harm to human or forbid man-entry. The situation inside the pipe will be recorded and displayed on the monitor screen; it also facilitates working personnel for effective observation, detection, quick analysis and diagnosis.


    Cctv Pipe Inspection Cameras Features:


    1. High Definition Camaera, 1920*1080P

    2. Portable control unit

    3. Windows operation system

    4. Powerful crawler drive

    5. Interchangeable parts


    Cctv Pipe Inspection Cameras Configuration


    Standard ConfigurationOptional Parts
    TVS15 crawlerCAM-70 camera
    CAM-90 pan & tilt cameraJT360 fish-eye camera
    Automatic cable drumManual cable drum
    MK4 control unitWheel support
    Manhole hook, tool box and other accesories10" wheel




    Technical Parameter


    Control Unit MK4

    HD CCTV Pipe Inspection Equipment 360 Degree Drain Camera System



    1. Pad Style Control Unit, 8.4' Touched LED, Readable in Sun Shine, 1024*768 resolution, 4.1kg
    2. Win10 system, 128GB SSD, Record video in site, 100+ hours video can be saved.
    3. Camera position, elevator position in Graphs
    4. Inclination report in site.
    5. System status, work parameter can be query.


    Pan&Tilt Camera CAM-90HD CCTV Pipe Inspection Equipment 360 Degree Drain Camera System



    1. Rotation: 360 degree horizontal, 270 degree vertical

    2. 120x zooming, 10:1 optical, 12:1 digital

    3. Auto focus, manual adjustment is allowed

    4. Digital hidh definition, 1920*1080P

    5. Camera lens anti-fogged
    6. Laser scanning the pipe diameter and distortion

    7. Laser gauge to measure the defect size
    8. Camera light can be adjusted to adapt different pipes.

    Cralwer TVS-15

    HD CCTV Pipe Inspection Equipment 360 Degree Drain Camera System


    1. Waterproof to IP68
    2. Working temperature: -10ºC~50ºC
    3. Suitable pipe diameter: 125mm~2000mm
    4. Drive: two DC motor, six wheels

    5. Sonde location: 33kHz
    6. Inclination: mesurement scope ±45 degree
    7. Climbing: max. climb degree about 50° according to diffrerent pipe status
    8. High definition rear sight camera and light: inspect crawler backwards and cable retreiving


    Automatic Cable Drum DLPA200HD

    HD CCTV Pipe Inspection Equipment 360 Degree Drain Camera System



    1. LCD display panel

    2. Three kinds of working mode: auto, manual and auto retrieving only.

    3. Standard cable length: 200m

    4. Built-in wifi module, wireless tranmission

    5. Cable counter meter and auto layering

    6. Emergency stop


    Fish-eye camera JT360

    HD CCTV Pipe Inspection Equipment 360 Degree Drain Camera System



    1. View360 degree sight inside the pipe.
    2. 92 PCS high-light LED lamps, illumination reaches to 200lm
    3. Resolution: 3000k pixel, high quality picture.
    4. Waterproof: IP68, workable 10 meters underwater.
    5. The videos and pictures recorded by MK3 full-view camera can spread full-range picture inside the pipe by PanoProfile 3D software, and generate 2D profile picture, in order to realize accurate measurement of pipe defects, install 3D mould, and create inspection report.


    Wheel support

    assembed on the crawler to inpsect pipe diamter above 1000mm, equipped with 8" wheels or 10" wheels.
